This model utilizes heavy duty components in a compact design with few moving parts. Features simple modular construction that allows replacement of single pieces instead of entire weldments. The swooping pick up action that made the TuckAway® famous allows the operator to engage the cart to the lifter without any back-breaking lifting, regardless of terrain. Now with a more powerful wide foot 27k helical rotary actuator with easy to service split-body construction!
WD6795
Half-TuckAway® Lifter
WD6795
Half-TuckAway® Lifter
Specifications
Load Type | Rear-load |
---|---|
Operation | Rotary Actuator, US 2-Bar; Type B (ANSI Z245.60-2008) |
width | 24in |
height | 20.5in |
Mounting Height | 36-43in |
Resources
Description
Featured
- TuckAway® Lifter Performance
- ISO 9001 manufacturer
- Compatible with ANSI Type B carts
- 1,550 PSI required for 400 lbs
- 6-8 second cycle time @ 3 GPM
- 3 Year limited warranty
- Self-lubricated bearings at pivot points (w/zerks)
*Please Note: It is the purchaser’s responsibility to determine product suitability for a given application. Perkins Manufacturing cannot be held liable for errors or omissions. Call Perkins Manufacturing (708) 482-9500 for assistance in choosing a cart lifter.
